GF5-UL62D

GIVING YOU LIGHTWEIGHT OPTIONS

GIGAFLIGHT’s GF5-UL62D XLite coax cable is a suitable alternative for UH67163. Designed with high-end materials, this exceptionally lightweight 50 ohm coaxial cable delivers low loss performance while providing the shielding effectiveness necessary for today’s advancing technologies. The combination of a silver-plated copper flat spiral wrap inner shield and silver-plated, copper clad aluminum (SPCCA) braid provides ample protection without adding unnecessary weight.

GF5-UL104D

GIVING YOU LIGHTWEIGHT OPTIONS

GIGAFLIGHT’s GF5-UL104D XLite coax cable is a suitable alternative for UH44193. Designed with high-end materials, this exceptionally lightweight 50 ohm coaxial cable delivers low loss performance while maintaining the shielding effectiveness necessary for today’s advancing technologies. The combination of a silver-plated copper flat spiral wrap inner shield and silver-plated, copper clad aluminum (SPCCA) braid provides ample protection without adding unnecessary weight.

GF826A-H6A Cable Drawing

GF826A-H6A

CAT6A 10Gb ETHERNET CABLE

The GF826A-H6A delivers 10 Gigabit performance in accordance with ANSI/TIA 568 Category 6A standards up to 214ft (65.22m) and serves as a suitable electrical alternative to Axon P542810. Featuring a black Low Smoke Zero Halogen (LSZH) Hytrel jacket, this cable is ideal for applications where fire safety is critical, such as avionics and control systems.

This product is sold in bulk or as CAT6A tested assemblies, please contact GIGAFLIGHT for more information.

GF422E-USB2-5

GF422E-USB2-5

USB 2.0 DATA CABLE

The GF422E-USB2-5 is designed to meet the requirements of USB 2.0 applications up to 18ft. With a 100% foil and a 90% round wire braided shield, this design provides ample protection against EMI in the vast majority of applications. The GF422E-USB2-5 is an identical alternative for EMTEQ’s U090-0422-100 cable. Contact GIGAFLIGHT if you’re interested in having us build your USB cable assemblies.

GF82624C-USB31 Cable Drawing

GF82624C-USB31

USB 3.1 DATA CABLE

The GF82624C-USB31 from GIGAFLIGHT supports USB 3.1, 3.0, and is backwards compatible with 2.0 for versatile connectivity. This high-performance cable delivers uninterrupted data transmission up to 10 Gbps, making it ideal for in-flight connectivity, data transfer, and HD video streaming in demanding aerospace environments. Constructed with a twisted pair of 26 AWG silver-plated HSCA conductors and dual-layer shielding (100% composite foil and 80% silver-plated copper braid), it provides superior EMI protection. Advanced avionics systems depend on this cable to handle high volumes of data and video transmission instantly.

GF824C-7 Cable Drawing

GF824C-7

CAT7 10G ETHERNET CABLE

GIGAFLIGHT’s GF824C-7 is an identical alternative to PIC’s E74824, delivering 10G CAT7 data performance for demanding aerospace & defense applications. Featuring 4-24AWG stranded, silver-plated HSCA conductors with dual-layer high-temp insulation, 100% composite foil shield around each pair, and a 90% silver-plated copper braid shield, this cable provides superior reliability and flexibility. Perfect for airborne 10G Base-T CAT7 LAN applications such as cabin management systems, in-flight entertainment, and Ethernet backbones.

GF222E-CANB

INNOVATIVELY DESIGNED CAN BUS

The GF222E-CANB is an Aerospace-grade CAN Bus cable designed as a suitable alternative for Carlisle’s MX120-22-020 (formerly NGC875CAA-1). This 120 ohm cable features two 22AWG stranded, silver-plated copper conductors, high-temperature foamed fluoropolymer insulation, a 92% tin-plated copper shield, and a laser-markable Tefzel jacket.

The GF222E-CANB provides ample EMI protection and consistent performance for aerospace applications.

GF5-TX151D

HIGH PERFORMANCE TRIAXIAL CABLE

Designed to handle environments sensitive to EMI, the 50-ohm Triaxial cable GF5-TX151D, an identical alternative to L8620TX, is equipped with a stranded, silver-plated copper center conductor, dual tin-plated copper braid shields, and a durable, laser-markable ETFE jacket. This cable is perfect for applications like radar systems, where protection against RFI and noise is critical. With its additional outer braid shield, it minimizes noise pick-up and improves the signal-to-noise ratio. For the best results, use triaxial connectors that maintain the isolation of both shields.



GF7-290D Cable Drawing

GF7-290D

HIGH-DEFINITION 75 Ohm Coaxial VIDEO CABLE

The 75-ohm coaxial cable GF7-290D is an identical alternative to the commonly used V78209 cable, offering equivalent electrical performance, size, weight, connector compatibility, and application versatility. The double-shielded construction, 100% foil and 95% round wire braid shield, provides the necessary shielding effectiveness for vast majority of aerospace applications. The GF7-290D is recommended for SMPTE 259M and is also suitable for SMPTE 292, SMPTE 424, and 12G-SDI video applications.

GF424A-CAT5E Cable Drawing

GF424A-CAT5E

10/100BASE-T 2-PAIR ETHERNET CABLE

The GF424A-CAT5E is designed to deliver 10/100Base-T Gigabit performance in accordance to ANSI/TIA-568-C.2 up to 296ft. The GF424A-CAT5E is an identical alternative to PIC’s E20424 and a suitable alternative to Amphenol’s 922404. With a 100% foil and a 90% round wire braided shield and dual-wall construction, this design provides ample protection against EMI in the vast majority of applications. Product is sold in bulk or CAT5E tested assemblies. Please contact GIGAFLIGHT for a quote.

If your project requires a specific jacket color that is called out in the jacket color table, please contact us for availability.
