75 ohm Coaxial, Triax, & HDMI Cables

Lightweight, High temperature, flexible, low loss, high-tech cables designed specifically for aircraft / avionics systems and other harsh environments. Laser markable jackets with multiple color options.

GIGAVideo 75 ohm aircraft video cables are designed to shield against EMI, provide low-loss transmission of video for applications including cabin security, in-flight entertainment and cockpit displays. Cables and cable assemblies used within key avionic systems for corporate, civil and military aircraft and to FAA flammability requirements.

  • In-Flight Entertainment (IFE)
  • Cockpit Displays
  • Surveillance / Cabin Security Cameras
  • RS170 Video
  • SMPTE 292M Video
  • SMPTE 424M Video
  • Blu-Ray & High Definition Video
  • 75 ohm RF & HDMI video cable solutions

GIGAFLIGHT also offers 75 ohm coax & triax connectors designed to perform in demanding environments.

Additional Jacket Colors for Special Applications

If your 75 ohm video cable application requires a specific jacket color, GIGAFLIGHT can do that. Contact us for cable availability.

View Color & Application Table
ColorApplication
ClearStandard
WhiteLaser Markable
OrangeFlight Test Data

High Speed 2.0 HDMI

GF100-26HDMI

GF100-26HDMI Aerospace Grade HDMI Cable
AWG:26
Jacket Outer Diameter in (mm):0.296 (7.52)
Weight lbs/1000ft (kg/1000m):76 (113.1)
Cable Details  Burn Test

GF100-26HDMI-NX

Drawing of gf100-26hdmi-nx-cable
AWG:26
Jacket Outer Diameter in (mm):0.285 (7.24)
Weight lbs/1000ft (kg/1000m):66 (101.19)
Cable Details  Burn Test

75 Ohm HD Digital Video Coax

GF7-449D
AWG:26
SMPTE 292M HD-SDI ft (m) (Max Length):125 (38.10)
SMPTE 424M 3G-SDI ft (m) (Max Length):85 (25.91)
Jacket Outer Diameter in (mm):0.125 (3.175)
Weight lbs/1000ft (kg/1000m):15 (22.32)
Cable Details  Connectors

GF7-303D

GF7-303D 75 Ohm Coax HD Video Cable

Additional Jacket Colors in stock for special applications

P/N: GF7-303D-3OrangeFlight Test Data
AWG:26
SMPTE 292M HD-SDI ft (m) (Max Length):120 (36.6)
SMPTE 424M 3G-SDI ft (m) (Max Length):80 (24.4)
Jacket Outer Diameter in (mm):0.12 (3.05)
Weight lbs/1000ft (kg/1000m):11 (16.37)
Cable Details  Connectors  Burn Test

75 Ohm HD Digital Video Triax

GF7-TX303D

GF7-TX303D 75 Ohm Triaxial HD Video Cable
AWG:26
SMPTE 292M HD-SDI ft (m) (Max Length):120 (36.6)
SMPTE 424M 3G-SDI ft (m) (Max Length):80 (24.4)
Jacket Outer Diameter in (mm):0.16 (4.06)
Weight lbs/1000ft (kg/1000m):22 (32.74)
Cable Details  Connectors  Burn Test
